Panda

Create view hierarchies declaratively.

Quick Look

view.pd.add(
    imageView.pd.image(logoImage),
    label.pd.text("Logo").color(.red).font(size: 20),
    button.pd.title("Go").action(buttonTapped)
)

It’s much shorter and concise than the imperative API, and easier to edit than storyboards.

Installation

Carthage

github "wordlessj/Panda" ~> 1.0

CocoaPods

pod 'Panda', '~> 1.0'

Usage

Basics

ALL settable properties and set methods in UIKit and Core Animation are available in pd extension, set prefixes are removed.

Property and method names are notoriously verbose, they don’t fit nicely when written in a single line, so some of them are shortened. The complete mappings are documented in Name Mappings. Don’t be frightened by the long list, you don’t need to remember them all, just type original names, Xcode will help you fix it with a single click. Option-click the new name to see the original name if you forget what it is.

Views are configured and added to a superview as you see in Quick Look, you can also nest add() to create a more complex hierarchy, note that configuration by pd is optional.

view.pd.add(
    containerView.pd.clips(true).add(
        view1.pd.background(.red)
    ),
    view2
)

Other types that can be added by add*() methods are also supported, like UIGestureRecognizer and UILayoutGuide. Don’t put them all in one add() method, grouping is recommended.

view.pd.add(
    // view hierarchy
).add(
    layoutGuide.pd.id("center guide")
).add(
    tapGestureRecognizer.pd.taps(2).action(doubleTapped)
)

Objects can be configured inline and passed to a method, if the method accepts a *Convertible.

// mask() accepts a UIViewConvertible.
// You can pass a plain or configured UIView.
view.pd.mask(
    maskView.pd.background(.white)
)

Add and Remove

add() and remove() methods are available on types below, followed by types that can be added. remove() is basically used to remove multiple object at once without configuration.

Type Types which can be added
CALayer CALayer, CAAnimation
UIAlertController UIAlertAction, UIViewController, UIKeyCommand
UIDynamicAnimator UIDynamicBehavior
UIDynamicBehavior UIDynamicBehavior
UIView UIView, UIGestureRecognizer, UIMotionEffect, NSLayoutConstraint, UILayoutGuide, UIInteraction
UIViewController UIViewController, UIKeyCommand

UIView is added to UIStackView using addArrangedSubview().

Custom Properties

With smart key paths, you can use set() to set custom properties not found in Panda.

customView.pd.set(\.flashes, true)

Action

Target-actions are replaced with action() taking a closure. They’re available on following types.

  • CADisplayLink, an initializer instead of action().
  • UIAccessibilityCustomAction
  • UIBarButtonItem
  • UIControl
  • UIGestureRecognizer

Font

UIFont factory methods are available directly as following methods.

  • font(style:)
  • font(style:compatibleWith:)
  • font(size:)
  • font(size:weight:)
  • font(boldSize:)
  • font(italicSize:)
  • font(monospacedDigitSize:weight:)

They’re available on following types.

  • UIButton, set font of titleLabel.
  • UILabel
  • UISimpleTextPrintFormatter
  • UITextField
  • UITextView

Transform

There’re several convenient methods to set transform on UICollectionViewLayoutAttributes and UIView. Each of them has a corresponding concat*() method to concatenate a transform to existing transform.

  • rotation(radian:)
  • rotation(degree:)
  • scale(x:y:)
  • scale(_:)
  • translation(x:y:)

Control States and Bar Metrics

For set methods taking a UIControlState or UIBarMetrics like title(_:for:), there’re convenience methods to set for all states or metrics like title(_:highlighted:selected:disabled:), the first parameter is for normal state, and the other parameters are optional.

Compositions

For convenience, there’re several composition methods which set multiple properties at once.

Types Composition Components
CALayer border borderWidth, borderColor
CALayer shadow shadowOpacity, shadowRadius, shadowOffset, shadowColor, shadowPath
UICollectionView, UIPageViewController, UIPickerView, UITableView sourceDelegate dataSource, delegate
UILabel shadow shadowColor, shadowOffset
UIScrollView alwaysBounce alwaysBounceHorizontal, alwaysBounceVertical
UIScrollView showsIndicators showsHorizontalIndicator, showsVerticalIndicator
UIView border layer.border
UIView cornerRadius layer.cornerRadius, layer.masks to true
UIView rasterized layer.rasterized, layer.rasterizationScale to screen's scale
UIView shadow layer.shadow

Set-Like Methods

Some methods don’t begin with set but are usually called while configuring, they are available as well.

  • UIAlertController.pd.addTextField(configure:)
  • UIGestureRecognizer.pd.require(toFail:)

Register and Dequeue

For UICollectionView and UITableView, an identifier is required when registering and dequeuing cells and views, and force casting to a specific type is usually needed. In practice, one identifier is associated with one specific type, so you can use the type itself instead of an identifier.

collectionView.pd.register(CustomCell.self)

let cell: CustomCell = collectionView.pd.dequeue(CustomCell.self, for: indexPath)

Reuse

If more than one object share similar configurations, or you want to create something like CSS, you can extract configurations into a method, then apply the method using do().

view.pd.add(
    firstLabel.pd.do(configLabel),
    secondLabel.pd.do(configLabel)
)

func configLabel(_ label: UILabel) {
    label.pd.color(.red).font(size: 20).lines(0)
}
