# Diagrams

# Overview

SpreadsheetWEB features over a dozen types of dashboard diagrams you can use to visualize your data in Dashboard applications. Below is an overview of each diagram type.

### Abacus Diagram

Abacus diagram works similar to a bar chart. Magnitudes are plotted on a grid matrix and this visualization makes it easier to track how each item compare to the rest in up to two groupings. Abacus diagram requires at least one **Source** and one **Measure** data. You can add more than one data to the **Measure** field to create multiple series. Alternatively, you can select a Group to separate the **Source** data accordingly. Please note that the **Measures** need to contain numeric fields and remember to select an **Expression** for each numeric **Measure** field by clicking on the field first and then choosing from the drop down.

### Bubble Diagram

**Source**and one

**Measure**data. You can also select a

**Group**to separate the

**Source**data accordingly. Please note that the

**Measure**needs to contain numeric fields and remember to select an

**Expression**for the

**Measure**field by clicking on the field first and then choosing from the drop down.

### Bullet Diagram

**Source**,

**Measure**and

**Marker Fields**only accept one numeric data column as input. You can also select any number of columns for

**Range Fields**. These will form the qualitative ranges, in the order they are selected. Please remember to select an

**Expression**for data in the

**Measure**field by selecting it first, and then choosing from the drop down.

### Calendar Map

**Date Field**and

**Measure**fields only accept one numeric data column as input. Please note that the

**Date Field**column data needs to be in date format, while

**Measure**can be either text or numeric data. Remember to select an

**Expression**if you select numeric data for

**Measure**. You can do this by clicking on the field first and then choosing from the drop down. If you select non-numeric data, the

**Expression**will be

**Count**.

### Circle Clusters

Circle clusters diagram plots a dataset against a given measure. This diagram is most useful for identifying where groupings occur in the comparison measure. A circle cluster accepts only one

**Source**, one

**Group Field**and one

**Measure**data. Please note that the

**Measure**needs to contain numeric fields and remember to select an

**Expression**for the

**Measure**field by clicking on the field first and then choosing from the drop down.

### Chord Diagram

Chord diagram represents inter-relationships in a data matrix. It does a great job at showing numerous connections at once. A wheel of points are connected with chords. **Source**, **Target** and **Measure** fields only accept one numeric data column as input. You can also select a Group to color the **Source** data accordingly. Please remember to select an **Expression** for data in the **Measure** field by selecting it first, and then choosing from the drop down.

### Circle Packing

Circle packing is a hierarchy diagram and is often used for visualizing breakdown of groupings in large data. Children nodes are packed into parent nodes and represent the magnitudes with their size. A circle packing requires one numeric data column for **Measure** and at least two numeric data columns for **Source** field. You can add more than two data to the **Source** field to create multiple layers. The hierarchy will be formed in the order you add the data to the **Source** field. Please remember to select an **Expression** for data in the **Measure** field by selecting it first, and then choosing from the drop down. When you click on any node, the diagram will zoom in and show the subgroup in detail.

### Co-Occurence Matrix

Co-Occurrence matrix shows the distribution of co-occurring values in a dataset. For instance, this diagram can easily reveal the interactions of a group of people. **Source**, **Target** and **Measure** fields only accept one numeric data column as input. This diagram also counts the times the source and target values meet and shows this measure on intersections. Please remember to select an **Expression** for data in the **Measure** field by selecting it first, and then choosing from the drop down.

### Dendrogram

Dendrogram is a hierarchy diagram that shows the relationship between sequentially merged classes. The data can be visualized in a **linear** or a **radial** fashion. Arcs connect the nodes of data. A dendrogram requires one **Measure** and at least two **Source** data columns for input. You can add more than two data to the **Source** field to create multiple layers. The hierarchy will be formed in the order you add the data to the **Source** field. Please remember to select an **Expression** for data in the **Measure** field by selecting it first, and then choosing from the drop down.

Linear | Radial |
---|---|

### Force Directed Graph

Force directed is great for outlining a hierarchy. Network diagrams, sales data and similar cases are common examples. Force directed requires at least one **Source**, while accepting only one Measure data. Please note that the **Measures** need to contain numeric fields and remember to select an **Expression** for each numeric Measure field by clicking on the field first and then choosing from the drop down.

### Gantt Diagram

Gantt diagrams are great for illustrating a project schedule. Gantt diagrams show the start and finish dates of the projects, and the percentage complete. A Gantt diagram requires at least one **Task**, one **Start** and one **End** data. Please note that **Start** and **End** need to be date data. Alternatively, you can select a **Group** to separate the **Task** data accordingly.

### Heatmap

Heatmap represents data in matrix format with added color coding, to signify corresponding magnitudes. Working pretty much like a pivot table, a heatmap accepts one **Row Field**, one **Column Field** and one **Measure** data columns for input. Remember to select an **Expression** if you select numeric data for **Measure**. You can do this by clicking on the field first and then choosing from the drop down. If you select non-numeric data, the expression will be **Count**.

### Matrix Diagram

A matrix diagram is great for comparing three different variables at the same time. Circles are positioned on the diagram as they correlate to the X and Y axis variables and the variable is represented through the size of the circle. A matrix diagram accepts one **Row Field**, one **Column Field** and one **Measure** data columns for input. Remember to select an **Expression** for **Measure**. You can do this by clicking on the field first and then choosing from the drop down. If you select non-numeric data, the **Expression** will be **Count**.

### Mirrored Bars

Mirrored bars are useful for comparing two measures of a source data side by side. Both axes use the same increments and this diagram looks best when the two measures include close values. A mirrored bars diagram requires one **Source** and two **Measure** data. Please note that the **Measure **fields need to contain numeric data and remember to select an **Expression** for each numeric **Measure** field by clicking on the field first and then choosing from the drop down.

### Network Diagram

Network diagram is most useful if a one-way relationship between the elements exists. For example, it can be used to graph the number of students assigned to a faculty member. Network diagram only accepts one data column for **Source**, **Target**, **Relation Field** and **Measure** fields. Please note that the **Measures** need to contain numeric fields and remember to select an **Expression** for each numeric **Measure** field by clicking on the field first and then choosing from the drop down.

### Parallel Lines

Parallel lines diagram looks like a time series visualization, but the axes actually don’t have to be in a particular order. It is commonly used for comparing quantitative measures of one parameter, side by side. A parallel lines diagram accepts one **Source** and two or more **Measure** data columns for input. Alternatively, you can also select a **Group** to color the **Source** data accordingly. Please note that the **Measure** needs to contain numeric data and remember to select an **Expression** for this field by selecting it first, and then choosing from the drop down.

*image coming soon

### Sankey Diagram

Sankey diagram represents a flow of a measure between two or more dimensions. It’s often used for visualizing a distribution of re**Source**s or cash flow. Sankey diagram accepts one **Measure** and two or more **Source** data columns for input. The columns selected for **Source** will be placed from left to right, in the order they are selected. Please note that the **Measure** needs to contain numeric data and remember to select an **Expression** for this field by selecting it first, and then choosing from the drop down.

### Seat Map

Seating arrangements or organization charts are where the seat map shines. This diagram comes in **Linear **and **Radial** flavors. The first looks great when visualizing a hierarchy or distribution, while the latter literally shows the composition of items, in a theater seating format. A seat map accepts one **Group** and one **Source** data. **Source**** **field can contain numeric or text data. This diagram doesn’t apply any expression to numeric data.

Linear | Radial |
---|---|

### Slope Graph

Slope graph compares the trend of one field against two groups. This diagram only displays an A to B relation; the points in between are not relevant. This diagram is fairly similar to a line multiples with an emphasis on the start and end points. A slope graph accepts one **X-Axis**, one **Y-Axis** and up to two **Group Fields**. If you select numeric data for the **Y-Axis** field, please remember to select an **Expression** by clicking on the field first and then choosing from the drop down.

### Streamgraph

Streamgraph is a variation of stacked area chart, displaced around a central axis with smooth lines. A streamgraph accepts one **X-Axis Field**, one **Group Field** and one **Measure** data column for input. Please note that the **X-Axis Field** and **Measure** need to contain numeric data and remember to select an **Expression** for the **Measure** field by selecting it first, and then choosing from the drop down.

### Sunburst Diagram

Sunburst diagram is essentially a variation of pie chart. While pie chart has only one dimension representing the size of each pie, sunburst diagram has multiple numeric fields each representing a ring around the previous one. A sunburst diagram accepts one **Measure** and two or more **Source**data columns for input. The hierarchy will be formed in the order you add the data to the **Source**field. Please note that the **Measure** needs to contain a numeric field and remember to select an **Expression** for this field by selecting it first, and then choosing from the drop down.

### Timeline Diagram

A timeline is a graphical way of displaying a list of events in chronological order. A timeline requires at least one **Source** and one **Start Date** data. Without an **End Date**, it will work pretty much like a calendar map. Alternatively, you can select a **Group** to separate the **Source** data accordingly.

### Treemap

Treemap is a diagram that visualizes hierarchical data in form of nested rectangles. The size of the rectangles represent quantity, while the color code helps compare the magnitudes within each group. A treemap accepts any number of **Source** fields and one **Measure** field for input. The hierarchy will be formed in the order you add the data to the **Source** field. **Measure** determines the size of the rectangles. Please note that the **Measure **field needs to contain numeric fields and remember to select an **Expression** for the **Measure **data by selecting it first, and then choosing from the drop down.

### Word Cloud

Word cloud represents text data visually. It is commonly used to analyze long texts or survey answers. Word cloud requires only one **Source** data column. The words will be sized depending on how many times they repeat in the data. You can also make the diagram **Exclude Stop Words**, such as “and, or, but”. Simply check this option in the Layout tab.
