Version License Platform


To run the example project, clone the repo, and run pod install from the Example directory first.



  • iOS 9.0+
  • Interoperability with Swift 5.0+



ShortClipVideoTrimmerUI is available through CocoaPods. To install it, simply add the following line to your Podfile:

pod 'ShortClipVideoTrimmerUI'


⚠️ This library doesn’t provide any Trimming Implementations. It has just provided the UI with video frames. You’ll get trimming area (means trimming start time and trimming finish time) and then you can do anything with these informations.


Create an instance (in interface builder or through code) of the ShortClipVideoTrimmerContentView and add it to your view hierarchy.

    shortClipTrimmerContentView.delegate = self // shortClipTrimmerContentView is an instance of ShortClipVideoTrimmerContentView
    shortClipTrimmerContentView.startOperation(asset: asset, maxTrimmingDuration: maxTrimmingDuration, numberOfFramesPerCycle: numberOfFramesPerCycle)

Here asset is type of AVAsset. You have to specify how much maximum trimming duration (which is maxTrimmingDuration) you need and how many frames should be shown per cycle (which is numberOfFramesPerCycle). Then create a AVPlayer or something releated to AVPlayer. provide a timer which transferes current time of running Video. For example

// videoPlayer is an instance of AVPlayer
videoPlayer.addPeriodicTimeObserver(forInterval: CMTime(seconds: 0.01, preferredTimescale: 600), queue: .main) {  _ in
    shortClipTrimmerContentView.updatePositionBarConstraint(cmTime: videoPlayer.currentTime())

you can also customize the ShortClipVideoTrimmerContentView by changing it’s color and width’s of subcomponents.

shortClipTrimmerContentView.updateHandlerWidth(width : 10.0)
shortClipTrimmerContentView.updateKnobWidth(width : 3.0)
shortClipTrimmerContentView.updatePositionBarWidth(width : 4.0)
shortClipTrimmerContentView.updateTrimmingAreaBorderWidth(width : 2.0)
shortClipTrimmerContentView.handlerColor(color :
shortClipTrimmerContentView.updateTrimmingAreaBorderColor(color :
shortClipTrimmerContentView.updateKnobColor(color : UIColor.white)
shortClipTrimmerContentView.updatePositionBarColor(color : UIColor.white)
shortClipTrimmerContentView.updateTrimmingOutsideBackgroundColor(color : UIColor.white)
shortClipTrimmerContentView.updateTrimmingOutsideMaskAlpha(alpha : 0.5)

By conforming ShortClipVideoTrimmerContentViewDelegate you’ll get the information about when trimming start and end position is changed. For better understanding please see the example project.


Sagar Chandra Das, [email protected]


ShortClipVideoTrimmerUI is available under the MIT license. See the LICENSE file for more info.
